| Business Type | Supplier, Retailer, Distributor, Importer |
| Brand Name | TVS |
| Shape | Square |
| Color | Black |
| Click to view more | |
Product Details
SPECIFICATIONS
Print method
Resolution
203DPI | 300DPI
Print width
108mm(Max.) | 106mm (Max.)
Print speed
152mm/s(Max.) | 102mm/s(Max.)
Memory
SDRAM: 32MB,
Flash:16MB(64MB optional)
Sensor
Photoelectric sensor
TPH temperature detection
Thermistor
TPH position detection
Microswitch
Interface
Standard USB port
Optional: RS232 serial port, Ethernet, Bluetooth, WiFi (Bluetooth or WiFi)
CPU
32bit RISC MCP
Barcodes
1D: Code39,Code93,Codabar,Code128(Subsets A, B, and C),EAN-13,EAN-8,UPC-A,UPC-E,UPC/EAN Extensions, Planet Code, Standard 2 of 5,Industrial 2 of 5,Interleaved 2 of 5,LOGMARS,G51 Data Bar(RSS)
2D: PDF 417,MicroPDF417,QR Code,DataMatrix,MaxiCode,GS1 Composite
Character enlargement/rotation
Rotate (0°, 90°, 180°, 2701 Enlarge (1-10x)
Vector fonts support stepless scaling
Character set
Built in 7 dot matrix fonts and 1 vector font
Support users to download dot matrix fonts and vector fonts
Graphical
Binary non-format bitmap, HEX, PCX, BMP and IMG can be download to FLASH, RAM
Paper type
Continuous paper, marking paper, label paper, perforated paper
Paper width
118mm (Max.)
Paper roll OD (Max.)
127mm(5 inch)
Paper roll ID
25.4mm(1 inch) /38mm(1.5 inch)
Paper out
Tear off/ Rewind/ Peel off (optional)/Cut (optional)
Paper thickness
0.06-0.25mm
Ribbon length
300m(Max.)
Ribbon ID
12.7mm/25.4mm
Button, Indicators
1 button,2 indicators
Input
100-240V AC, 50-601-b
Output
24V DC, 2.5A
Operation conditions
5-45°C, 20 – 90%RH(40°C)
Storage conditions
-40-60°C, 20 – 93% RH(40°C)
Dimensions
280mm(L) x218mm(VV)x180mm(H)
Weight
About 2.3kg
